| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | COIL COMP IGN(MP3 | 30510K1BT01 | - |
| 2 | CLAMP H/T CORD | 30511K04930 | - |
| 3 | SPACER IGN COIL | 30520GFM900 |
|
| 4 | CAP ASSY NOISE | 30700KTW901 | - |
| 5 | REG RECT ASSY | 31600K1BT01 | - |
| 6 | RECT.COMP.,SILICON | 31700MM8610 | - |
| 7 | HARNESS WIRE | 32100K2AN00 | - |
| 7 | 42 | 32100K2AM00 | - |
| 8 | SUSP CONNECTOR | 32111K1BT00 | - |
| 9 | DUMMY WPC 2P 090 | 32605KCWJ91 |
|
| 10 | SWITCH ASSY HNDL | 35100K1BT01 | - |
| 11 | SWITCH COMP HNDL | 35101K1BT01 | - |
| 12 | 35111K0SN12 | 35121K2AN00 | - |
| 12 | 42 | 35121K2AM00 | - |
| 13 | SET SMART CONTROL | 35141K2AN00 | - |
| 13 | 42 | 35141K2AM00 | - |
| 14 | BATTERY | 35148K78N10 |
|
| 14 | 35148K78N10 | 72148S04000 | - |
| 15 | 35160KPPT02 | 35160KPPT01 | - |
| 16 | COLLAR | 35162MGC003 |
|
| 17 | GROMMET | 35163MGC003 |
|
| 18 | COVER CABLE | 35191K53D01 |
|
| 19 | SW ASSY SEAT OPEN | 35193K1BT01 | - |
| 20 | KEY SET, EMERGENCY | 35194K0RV01 | - |
| 21 | HORN COMP(HIGH) | 38110K27M01 | - |
| 22 | SUSPENSION RELAY | 38200K0BT00 | - |
| 23 | RELAY COMP LED | 38301MKJD01 | - |
| 24 | SUSPENSION RELAY | 38306KK4000 |
|
| 25 | RELAY COMP., POWER | 38501KWN901 |
|
| 26 | RELAY COMP POWER | 38502GGZJ01 |
|
| 27 | BUZZER ASSY NG LIGHT | 38720K66V11 |
|
| 28 | UNIT COMP PGM-FI/ | 38770K2AN01 | - |
| 28 | 42 | 38770K2AM01 | - |
| 29 | CUSH PGM-FI/IGN U | 38771K1BT00 | - |
| 30 | UNIT ASSY USB CHA | 38940K1BT01 | - |
| 31 | SENSOR ASSY AMBIE | 80525TBAA01 |
|
| 32 | SCREW OPENER SET | 90104K53D01 |
|
| 33 | SCREW U-LOCK FLAT 6X12 | 90164KZLA00 |
|
| 34 | BAND, WIRE HARNESS | 90620SB2003 | - |
| 35 | CLAMP, HARNESS | 90652HC4003 | - |
| 36 | CABLE STRAP | 90672SB2003 | - |
| 37 | CLIP, COUPLER(DARK BROWN) | 91535TA0003 |
|
| 38 | CLIP REL HOLDER(NATURAL) | 91536STK003 |
|
| 39 | CLIP, COUPLER(BLACK) | 91565SEL003 |
|
| 40 | DUMMY WPC 6P 025M | 91771MKKH11 |
|
| 41 | BOLT HEX 6X20 | 92101060204J |
|
| 42 | BOLT-WASH. 6X25 | 934030602500 | - |
| 43 | SCREW,TAPP 4X12 | 9390124320 |
|
| 44 | BOLT FLANGE 6X12 | 957010601200 |
|
| 45 | BOLT FLANGE M6 X 14 | 957010601407 |
|
| 46 | BOLT FLANGE 6X22 | 957010602200 |
|
| 47 | BOLT,FLANGE 8X14 | 957010801400 |
|
| 48 | FUSE, MINI(5A) | 9820040500 |
|
| 49 | FUSE F (7,5A) | 9820040750 |
|
| 50 | FUSE, MINI(10A) | 9820041000 |
|
| 51 | FUSE F (15A) | 9820041500 |
|
| 52 | FUSE 30A (MINI) | 9820043000 |
|
