| 1 |
CRANK CASE COMP R |
11100K2AJ00 |
-
|
| 2 |
BUSH OUTER R ENG |
11103K04930 |
-
|
| 3 |
BUSH OUTER L ENG |
11104K04930 |
-
|
| 4 |
BUSH INNER ENG.HAD |
11105KTW900 |
-
|
| 5 |
CRANK CASE COMP L |
11200K1BT00 |
-
|
| 6 |
GASKET OIL PATH |
11205KTW900 |
-
|
| 7 |
BRG CRANK SHAFT RN2-TYPE) |
13312KTW901 |
-
|
| 7 |
BRG CRANK SHAFT RN2-TYPE) |
13313KTW901 |
-
|
| 7 |
BRG CRANK SHAFT RN2-TYPE) |
13314KTW901 |
-
|
| 7 |
BRG CRANK SHAFT RN2-TYPE) |
13315KTW901 |
-
|
| 7 |
BRG CRANK SHAFT R |
13316KTW901 |
-
|
| 7 |
BRG CRANK SHAFT R |
13317KTW901 |
-
|
| 7 |
BRG CRANK SHAFT R |
13318KTW901 |
-
|
| 7 |
BRG CRANK SHAFT R |
13319KTW901 |
-
|
| 8 |
BRG CRANK SHAFT L |
13322KTW901 |
-
|
| 8 |
BRG CRANK SHAFT L |
13323KTW901 |
-
|
| 8 |
BRG CRANK SHAFT L |
13324KTW901 |
-
|
| 8 |
BRG CRANK SHAFT L |
13325KTW901 |
-
|
| 8 |
BRG CRANK SHAFT L |
13326KTW901 |
-
|
| 8 |
BRG CRANK SHAFT L |
13327KTW901 |
-
|
| 8 |
BRG CRANK SHAFT L |
13328KTW901 |
-
|
| 8 |
BRG CRANK SHAFT L |
13329KTW901 |
-
|
| 9 |
SET,OIL FILTER |
15010MKR305 |
|
| 10 |
STRAINER OIL |
15153HN7000 |
-
|
| 11 |
COLLAR O RING |
15155300000 |
-
|
| 12 |
COLLAR O RING |
15155HP0A00 |
-
|
| 13 |
JET COMP PISTON |
15201K1BT00 |
-
|
| 14 |
VALVE ASSY RELIEF |
15220K53D00 |
-
|
| 15 |
VALVE RELIFE |
15231413020 |
-
|
| 16 |
CARTRIDGE, OIL FILTER |
15410MFJD02 |
|
| 17 |
SCREEN OIL FILTER |
15421K04930 |
-
|
| 18 |
WIRE HARN OIL P S |
32120K1BT00 |
-
|
| 19 |
SWITCH ASSY., OIL PRESSURE |
35500MEH661 |
-
|
| 20 |
GUIDE OIL PRESSERLESS ENTRY |
38515KTW900 |
-
|
| 21 |
BUSH DAMPER DISTANCE |
52108KTWB00 |
-
|
| 22 |
BOLT PLUG DRAIN 1N |
90002KTW900 |
-
|
| 23 |
BOLT-WASHER, 4X8(DENSO) |
90002PA6003 |
-
|
| 24 |
BOLT,SPL 6X14 |
90004K0JN00 |
|
| 25 |
BOSS, OIL FILTER |
90019MGZJ00 |
-
|
| 26 |
WASHER,8MM |
90474333000 |
|
| 27 |
CIRCLIP IN 65 |
90601K1BT00 |
-
|
| 28 |
BRG BALL RADIAL 2 |
91001K1BT01 |
-
|
| 29 |
BRG BALL RADIAL 6 |
91003K1BT01 |
-
|
| 30 |
BRG BALL RADIAL 6 |
91007KTW901 |
-
|
| 31 |
OIL SEAL 33X64X7 |
91201K04931 |
-
|
| 32 |
OIL SEAL 25X35X5 |
91201K53D01 |
-
|
| 33 |
O-RING 14.8X2.4 |
91303K04930 |
-
|
| 34 |
O-RING 15.8X2.4 |
91304K04930 |
-
|
| 35 |
O-RING 16.5X2.5 |
91305K04930 |
-
|
| 36 |
O-RING,3.8X1.4 |
91305K0JN00 |
|
| 37 |
O-RING 9.8X2.4 (ARAI) |
91307K04930 |
-
|
| 38 |
O-RING 14.7X2.2 |
91313K04930 |
-
|
| 39 |
WASHER PLAIN 5MM |
9410105800 |
|
| 40 |
WASHER, DRAIN PLUG, 12MM |
9410912000 |
|
| 41 |
DOWEL,PIN,10X16 |
9430110160 |
|
| 42 |
CIRCLIP 12MM |
9452012000 |
|
| 43 |
CLIP RISTON.PIN |
9460116000 |
-
|
| 44 |
CLIP,TUBE 5.0 MM |
9500250000 |
|
| 45 |
TUBE,5X110 |
950055011030 |
|
| 46 |
BOLT FLANGE 6X55 |
957010605500 |
|
| 47 |
BOLT, FLANGE, 6X75 |
957010607500 |
-
|
| 48 |
BOLT, FLANGE, 8X12 |
957010801200 |
|
| 49 |
BOLT FLANGE 8X50 |
957010805000 |
|
| 50 |
ROLLER 3X17.8 |
9622030178 |
-
|
