| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | 64311K3NN00ZA | 64311K3NN00ZA | - |
| 2 | COVER,R FLOOR SIDE,NH-436M | 64321K3NN00ZA | - |
| 2 | COVER,R FLOOR SIDE,NH-C51P | 64321K3NN00ZB | - |
| 2 | COVER,R FLOOR SIDE,NH-C35M | 64321K3NN00ZC | - |
| 3 | COVER,L FLOOR SIDE,NH-436M | 64322K3NN00ZA | - |
| 3 | COVER,L FLOOR SIDE,NH-C51P | 64322K3NN00ZB | - |
| 3 | COVER,L FLOOR SIDE,NH-C35M | 64322K3NN00ZC | - |
| 4 | COVER,UNDER | 64331K3NN00ZA | - |
| 5 | LID,BATTERY | 64460K3NN00ZA | - |
| 6 | COVER,R PILLION STEP | 83511K3NN00ZA | - |
| 7 | COVER,L PILLION STEP | 83611K3NN00ZA | - |
| 8 | SCREW,PAN 5X13.5 | 90101K2FN00 |
|
| 9 | BOLT FLANGE 5MM | 90113K84900 |
|
| 10 | SCREW, SPECIAL, 5X11 | 90114K98E20 | - |
| 11 | RIVET,PUSH 6MM | 90116K3VN01 |
|
| 12 | NUT SPRING 4MM | 90302KWWA00 |
|
| 13 | CLIP SNAP FIT(PO) | 90666K59A11 |
|
| 14 | NUT CLIP 5MM. | 90677KANT00 |
|
| 15 | BOLT WASHER 6X12 | 934040601200 |
|
| 16 | SCREW TAPPING 4X16 | 9390334480 |
|
