| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | SWITCH FR STOP ASSY | 35340MGSD31 |
|
| 2 | CLAMP, ABS CORD(12) | 38517MGE003 | - |
| 3 | 38520K1TE11 | 38520K1TE11 | - |
| 3 | 38520K1TE51 | 38520K1TE51 | - |
| 4 | 38525KZZJ80 | 38525KZZJ80 | - |
| 5 | CLIP, COUPLER(DARK BLUE) | 42524T5A003 |
|
| 6 | 45124K1TE11 | 45124K1TE11 | - |
| 6 | 45124K1TE51 | 45124K1TE51 | - |
| 7 | 45127K1TE11 | 45127K1TE11 | - |
| 7 | 45127K1TE51 | 45127K1TE51 | - |
| 8 | 45181KZZJ80 | 45181KZZJ80 | - |
| 8 | 45181KZZG40 | 45181KZZG40 | - |
| 9 | 45182KZZJ80 | 45182KZZJ80 | - |
| 10 | BOOT COMP | 45504410003 |
|
| 11 | SUB ASSY FR M/C AKE | 45510KZZ901 | - |
| 12 | CAP,MASTER CYL | 45513HA2006 |
|
| 13 | HOLDER MASTER CYL | 45517166006 |
|
| 14 | SEPARATOR COMP ER | 45518MENJ01 |
|
| 15 | DIAPHRAGM | 45520MG7006 |
|
| 16 | PLATE,DIAPHRAGM | 45521HA2006 |
|
| 17 | RING | 45523KA3731 |
|
| 18 | CYLINDER SET,MAS | 45530471831 |
|
| 19 | LEVER R STRG HNDL | 53175KZZ900 |
|
| 20 | 53176KZZ901 | 53176KZZ901 | - |
| 21 | BOLT FLANGE SH 6X12 | 90013GHB610 | - |
| 22 | BOLT FLANGE SH 6X | 90013GHB660 | - |
| 23 | BOLT FLANGE SH 6X | 90013GHB670 | - |
| 24 | BOLT, HANDLE LEVER PIVOT | 90114166006 |
|
| 25 | BOLT LEVER PIVOT | 90114KZZJ01 | - |
| 26 | BOLT FLANGE SH 6X | 90117KZZJ80 | - |
| 27 | BOLT OIL 10X22 | 90145MS9612 | - |
| 28 | WASHER OIL BOLT | 90545300000 |
|
| 29 | 90650KZZJ80 | 90650KZZJ80 | - |
| 30 | CIRCLIP | 90651MA5671 |
|
| 31 | CLIP | 90652HL4A01 | - |
| 32 | CLIP, CABLE, 12MM | 90690MGSD81 |
|
| 33 | SCREW FLAT, 4X12 | 93600040121G |
|
| 34 | SCREW WASHER 4X12 | 938930401217 |
|
| 35 | NUT,FLANGE 6MM | 9405006000 |
|
| 36 | BOLT,FLANGE 6X18 | 960010601807 |
|
| 37 | BOLT FLANGE 6X22 | 960010602207 |
|
