| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | COIL COMP IGN | 30510K1TE11 | - |
| 2 | SPACER IGN COIL | 30520GFM900 |
|
| 3 | CAP ASSY NOISE SU | 30700KZZ901 | - |
| 4 | REG RECT ASSY | 31600KZZJ01 | - |
| 5 | RECT.COMP.,SILICON | 31700MM8610 | - |
| 6 | DIODE ASSY,3WAY | 31730MAS601 |
|
| 7 | HARNESS WIRE | 32100K1TN00 | - |
| 7 | 32100K1TM10 | 32100K1TM10 | - |
| 7 | 32100K1TH00 | 32100K1TH00 | - |
| 7 | 32100K1TE10 | 32100K1TE10 | - |
| 7 | 32100K1TU10 | 32100K1TU10 | - |
| 8 | SUB HARNESS FR | 32103K1TT00 | - |
| 8 | 32100K1TU10 | 32103K1TE10 | - |
| 9 | CONNECTOR DIODE(2P)(3A) | 32146S84003 |
|
| 10 | BAND B1 WIRE /K5 | 32161404000 |
|
| 11 | DUMMY WPC 4P 090 | 32605GEV761 | - |
| 12 | SENSOR ASSY,BANK ANGLE M6 | 35160KVS751 |
|
| 13 | RUBBER HEAT GUARD | 35161K1TE10 | - |
| 14 | STAY BANK ANGLE S | 35161KZZ900 | - |
| 15 | RUBBER, SPEEDOMETER MOUNTING | 37244MM4000 | - |
| 16 | HORN COMP | 38110KPPT01 | - |
| 17 | RELAY COMP,LED WIN | 38301KZZJ01 |
|
| 18 | RELAY COMP LED | 38301MKJD01 | - |
| 19 | SUSPENSION RELAY | 38306KK4000 |
|
| 20 | RELAY COMP POWER | 38501MKRD11 | - |
| 21 | COVER RELAY(2P) | 38506KZZ900 | - |
| 22 | 38770K1TE11 | 38770K1TE11 | - |
| 22 | 38770K1TF11 | 38770K1TF11 | - |
| 23 | UNIT COMP PGM-FI/ | 38770K1TN01 | - |
| 23 | 38770K1TM11 | 38770K1TM11 | - |
| 23 | 38770K1TH01 | 38770K1TH01 | - |
| 24 | SUSPENSION UNIT C | 38771K1TE10 | - |
| 25 | SUSPENSION UNIT C | 38771K1TJ10 | - |
| 26 | COLLAR,FR FENDER | 61104428010 |
|
| 27 | RUBR.B SEAT MNT. | 77208KW7900 |
|
| 28 | COLLAR, PILLION SEAT | 77302473000 | - |
| 29 | WASHER B (L) | 90525030000 |
|
| 30 | BAND, WIRE | 90650KW3000 | - |
| 31 | BAND WIRE | 90651KV6003 |
|
| 32 | CLIP, COUPLER(DARK GRAY) | 91534SWA003 |
|
| 33 | CLIP, COUPLER(DARK BROWN) | 91535TA0003 |
|
| 34 | CLIP, COUPLER(DARK GREEN) | 91565S0X003 |
|
| 35 | CLIP, COUPLER(BLACK) | 91565SEL003 |
|
| 36 | DUMMY WPC 6P 025M | 91771MKKH11 |
|
| 37 | BOLT HEX 6X20 | 92101060204J |
|
| 38 | NUT,FLANGE 6MM | 9405006000 |
|
| 39 | BOLT FLANGE 6X10 | 957010601008 |
|
| 40 | BOLT FLANGE 6X30 | 957010603000 |
|
| 41 | BOLT, FLANGE, 6X32 | 957010603208 | - |
| 42 | BOLT FLANGE 8X12 | 957010801208 | - |
| 43 | FUSE, MINI(10A) | 9820041000 |
|
| 44 | FUSE 30A (MINI) | 9820043000 |
|
