| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | SPOKE SET,A 10X223.5 | 06420K84900 |
|
| 2 | SPOKE SET,A 10X222.5 | 06421K84900 |
|
| 3 | SPROCKET FINAL | 41201K84900 |
|
| 4 | AXLE RR WHEEL L | 42301K84900 |
|
| 5 | COLLAR L RR WHEEL | 42311K84900 |
|
| 6 | COLLAR RR BRK SIDE | 42312K84900 |
|
| 7 | COLLAR RR AXLE DIST | 42620KAE000 |
|
| 8 | HUB SUB ASSY,REAR | 42635K84900 |
|
| 9 | WHEEL SUB ASSY,REAR | 42650K84900 |
|
| 9 | WHEEL SUB ASSY,REAR | 42650K84920 |
|
| 10 | RIM, RR. WHEEL(18X2.15) | 42701K84901 |
|
| 10 | RIM, REAR WHEEL 18X2.15 | 42701K84921 |
|
| 11 | TIRE, RR.(IRC)(4.10-18 59P) | 42711K84901 |
|
| 12 | TUBE, TIRE(IRC)(4.10-18) | 42712K84901 |
|
| 13 | FLAP, TIRE(IRC) | 42713K84901 |
|
| 14 | CAP, RIM HOLE | 42717K84900 |
|
| 15 | DISK, RR. BRAKE(SUNSTAR) | 43251K84901 |
|
| 16 | BOLT BRK DISK 8X24 | 90105KGH900 |
|
| 17 | BOLT SPRKT FIX | 90125KZJ900 |
|
| 18 | NUT U 16 MM | 90306KCJ951 |
|
| 19 | NUT U 8MM | 90309ML3791 |
|
| 20 | WASHER 8MM | 90511KRH780 |
|
| 21 | WASHER RR AXLE | 90559K84900 |
|
| 22 | BRG, BALL RADIAL 6303U L (NACHI) | 91051K68901 |
|
| 23 | BEARINGBALL RADIAL 6203U L | 91054K03H01 |
|
| 23 | 91054K03H03 | 91054K03H02 | - |
| 23 | BEARINGBALL RADIAL 6203U L | 91054K03H03 |
|
| 23 | 91054K03H03 | 91054K03H04 | - |
| 23 | BRG BALL RADIAL 6203U L | 91054K03N41 |
|
| 24 | OIL SEAL, 25X40X7 | 91252KCY671 |
|
| 25 | OIL SEAL 25X47X6.5 | 91253033003 |
|
