| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CLAMPER A,BRK HOSE | 45461KZZ900 |
|
| 2 | CLAMPER COMP B,BRK HOSE | 45462KZZ900 |
|
| 3 | FORK ASSY., R. FR.(SHOWA) | 51400K84305 |
|
| 4 | SPRING, FR. FORK(SHOWA) | 51401K84901 |
|
| 5 | SPRING B, FR. FORK(SHOWA) | 51402K84901 |
|
| 6 | PLATE,SPG.JOINT | 51403ME4003 |
|
| 7 | GUIDE, SPRING(SHOWA) | 51404K84901 |
|
| 8 | TUBE, OUTER | 51410K84305 |
|
| 9 | RING,BACK UP | 51412461003 |
|
| 10 | SPRING, REBOUND | 51412K64N01 |
|
| 11 | BUSH, GUIDE | 51414K31901 |
|
| 12 | SEAT, SPRING | 51415K64N01 |
|
| 13 | BUSH, SLIDER | 51415KSEA71 |
|
| 14 | SEAT, STOPPER | 51419K64N01 |
|
| 15 | PIPE COMP., R. SLIDE | 51425K84305 |
|
| 16 | ROD COMP.(SHOWA) | 51426K84901 |
|
| 17 | DAMPER COMP., FR.(SHOWA) | 51430K84901 |
|
| 18 | RING,OIL SEAT STOP | 51447KR6003 |
|
| 19 | BOLT COMP., FR. FORK(SHOWA) | 51450K84901 |
|
| 19 | BOLT COMP, FR FORK | 51450K84921 |
|
| 20 | NUT, HEX., 10MM | 51451MAJG41 |
|
| 21 | RING, STOPPER | 51456K64N01 |
|
| 22 | RING WEAR | 51476GBF831 |
|
| 23 | SEAL SET, FR. FORK(SHOWA) | 51490K84901 |
|
| 24 | FORK ASSY., L. FR.(SHOWA) | 51500K84305 |
|
| 25 | PIPE COMP., L. SLIDE | 51525K84305 |
|
| 26 | PROTECTOR, R. FR. FORK | 51610K84900ZB |
|
| 26 | PROTECTOR, FR FORK R(BLK) | 51610K84900ZC |
|
| 27 | PROTECTOR, L. FR. FORK | 51620K84900ZB |
|
| 27 | PROTECTOR, FR FORK L(BLK) | 51620K84900ZC |
|
| 28 | BOLT FLANGE 6MM | 90113KZZ900 |
|
| 29 | BOLT PROTECTOR | 90113MAC780 |
|
| 30 | BOLT,SOCKET 8MM | 90116KV3701 |
|
| 31 | WASHER SPECIAL (8MM) | 90544283000 |
|
| 32 | SEAL, DUST | 91254GBF831 |
|
| 33 | O-RING, 37.2X2.4(SHOWA) | 91356MW0003 |
|
