| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | SET ILLUS,WIND SCREEN TYPE 1 | 64100K64NP0ZA |
|
| 1 | Cowl Fr Upper Wn Rd | 64210K64NP0ZD |
|
| 2 | Cowl Fr Upper (MT ZO BL) | 64210K64NP0ZE |
|
| 2 | Cowl Fr Upper (MA AX GY) | 64210K64NP0ZG |
|
| 2 | COWL,FR UPPER (BLK) | 64210K64NP0ZH |
|
| 2 | 64200K64NP0ZB | 64200K64NP0ZB | - |
| 2 | 64200K64NQ0ZA | 64200K64NQ0ZA | - |
| 2 | 64200K64NN0ZA | 64200K64NN0ZA | - |
| 2 | SET ILLUS,FR UPPER COWL TYPE 1 | 64200K64NR0ZA |
|
| 2 | 64200K64NP0ZA | 64200K64NP0ZA | - |
| 3 | WASHER SCREEN SET | 64205166610 |
|
| 4 | SET ILLUS,FR LOWER COWL TYPE 1 | 64220K64NP0ZA |
|
| 4 | 64220K64NN0ZA | 64220K64NN0ZA | - |
| 5 | STAY COMP., FR. UPPER COWL | 64221K64N00 |
|
| 6 | STAY, R. NUMBER PLATE | 64222K64N00 |
|
| 7 | STAY, COUPLER | 64223K64N00 |
|
| 7 | STAY,COUPLER | 64223K64NM0 |
|
| 8 | PANEL,METER | 64224K64NP0 |
|
| 9 | COVER,METER | 64225K64NP0 |
|
| 10 | STAY, L. NUMBER PLATE | 64232K64N00 |
|
| 11 | COVER, R FRONT SIDE (MT GN BL) | 64340K64NP0ZB |
|
| 11 | COVER, R FRONT SIDE (WN RD) | 64340K64NP0ZA |
|
| 11 | Cover R Front Side (WN RD) | 64340K64TG0ZC |
|
| 12 | WASHER,RUBBER | 64342K64NP0 |
|
| 13 | COVER,L FRONT SIDE (MT GN BL) | 64440K64NP0ZB |
|
| 13 | COVER,L FRONT SIDE (WN RD) | 64440K64NP0ZA |
|
| 14 | MIRROR ASSY, R BACK | 88110K64NA1 |
|
| 15 | MIRROR ASSY, L BACK | 88120K64NA1 |
|
| 16 | SCREW, SPECIAL, 5MM | 90104KPH900 |
|
| 17 | NUT COWL SET M5X0.8 | 90111KW3003 |
|
| 18 | RIVET PUSH 6MM | 90116K0AE11 |
|
| 19 | Clip Bumper Seal | 90116SP0003 |
|
| 19 | Clip Bumper Seal | 90116K2PV61 |
|
| 20 | BOLT SPECIAL 5X16 | 90119K45N00 |
|
| 21 | SCREW,PAN 5X14 | 90134KPPT00 |
|
| 22 | NUT HEX CAP | 90443107000 |
|
| 23 | WASHER, THRUST 5MM | 90504964000 |
|
| 24 | PUSH CLIP,AIR INT DUCT | 90601PV3003 |
|
| 25 | CLIP, WIRE HARNESS | 90650SD9003 |
|
| 26 | CLIP SNAP FIT (P0) | 90666SDAA01 |
|
| 27 | NUT CLIP 5MM. | 90677KANT00 |
|
| 28 | SCREW TAPPING 4X12 | 9390324380 |
|
| 29 | BOLT FLANGE 8X 32 | 958010803200 |
|
| 30 | BOLT, FLANGE, 6X10 | 960010601000 |
|
| 31 | BOLT SOCKET 6X16 | 966000601608 |
|
