| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CASE, DRIVE CHAIN | 40510K64N00 |
|
| 2 | CHAIN, DRIVE | 40540KYJ902 |
|
| 3 | ADJUSTER, CHAIN | 40544K64N00 |
|
| 4 | JOINT DRIVE CHAIN | 40545KYJ902 |
|
| 5 | BOLT, SWINGARM PIVOT | 52101K64N00 |
|
| 6 | COLLAR, PIVOT DISTANCE | 52102K64N00 |
|
| 7 | COLLAR, R. SWINGARM PIVOT | 52105K64N00 |
|
| 8 | COLLAR,PIVOT | 52106KYJ900 |
|
| 9 | CAP, RR. SWINGARM | 52161K64N00 |
|
| 10 | CAP, RR. SWINGARM CENTER | 52162K64N00 |
|
| 11 | SLIDER, CHAIN | 52170K64N00 |
|
| 12 | WASH.CHN.SLDR. | 52171KR6000 |
|
| 13 | SWINGARM SUB ASSY,RR | 52200K64NA0 |
|
| 14 | SCREW PAN,5X16 | 90104KPP900 |
|
| 15 | BOLT, SOCKET, 6X14 | 90111K64N00 |
|
| 16 | BOLT, HEX., 8X47.5 | 90112KZZ900 |
|
| 17 | NUT, U, 14MM | 90305GGZJ01 |
|
| 18 | NUT HEX 8MM | 90309357000 |
|
| 19 | WASHER, 14X28X2.6 | 90502K64N00 |
|
| 20 | BEARING, NEEDLE, 22X29X30(NTN) | 91071MJ0003 |
|
| 21 | OILSL,22X31X5 | 91205965003 |
|
| 22 | DUST SEAL,22X35X7 | 91213MB2003 |
|
| 23 | CIRCLIP IN 35 | 9452035000 |
|
| 24 | B/BRG RAD N/COM LBL | 961006202010 |
|
