| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | PAD SET, RR. | 06435K64N01 |
|
| 2 | SEAL SEAT PISTON | 6451443405 | - |
| 3 | CLAMP, PIPE | 17368KV7671 |
|
| 4 | SENSOR WHEEL SPD | 38510K64N11 |
|
| 5 | STAY, SENSOR CORD | 38514K64N10 |
|
| 6 | PISTON | 43107KT7761 |
|
| 7 | SPRING,PAD | 43108MBB006 |
|
| 8 | BRACKET COMP., RR. BRAKE | 43110K64N01 |
|
| 9 | BRACKET COMP., RR. BRAKE | 43110K64N11 |
|
| 10 | RETAINER | 43112KT7761 |
|
| 11 | BOLT, PIN | 43131KW3006 |
|
| 12 | BOOT,SLEEVE | 43132KT7761 |
|
| 13 | CALIPER SUB ASSY., RR. | 43150K64N01 |
|
| 14 | SCREW,BLEEDER | 43352568003 |
|
| 15 | CAP,BLEEDER | 43353461771 |
|
| 16 | SLEEVE | 45111MA3006 |
|
| 17 | O-RING,2.5X1.5 | 45111MAJG41 |
|
| 18 | BOOT B,PIN | 45133MA3006 |
|
| 19 | BOLT FLANGE NSHF | 90108K64N10 |
|
| 20 | BOLT,FLANGE,8X49 | 90180MN8006 |
|
| 21 | CLIP CABLE 14MM | 90690MCA003 |
|
| 22 | CLIP CABLE 14MM | 90690MCA003 |
|
