| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | Radiator Comp | 19010K64N01 |
|
| 2 | Shroud Comp | 19015K64N01 |
|
| 3 | Fan Comp Cooling | 19020K64N01 |
|
| 4 | Motor Comp Fan | 19030K64N02 |
|
| 5 | Cap Comp Radiator | 19037K64N01 |
|
| 6 | Seal Radiator Cap | 19055K64N01 |
|
| 7 | Cap Assy Reserve Tank | 19106GET000 |
|
| 8 | Packing Reserve Tank | 19107GET000 |
|
| 9 | Tube Overflow | 19107K64N00 |
|
| 10 | Clamp Reserve Tank Tube (GRAY) | 19108PHM003 |
|
| 11 | Tank Radiator Reserve | 19110K64N00 |
|
| 12 | Rubber Heat Guard | 19125K64N00 |
|
| 13 | Guard Radiator Lower | 19127K64N00 |
|
| 14 | Thermostat | 19300K64N01 |
|
| 15 | Case Comp Thermostat | 19311K64N00 |
|
| 16 | Cover Thermostat | 19315K64N00 |
|
| 17 | Hose Radiator Upper | 19501K64N00 |
|
| 18 | Sensor Assy Water Temp | 37870KZR601 |
|
| 19 | Grommet Ignition Cover | 53133KR1760 |
|
| 20 | Collar Radiator Mounting | 61102KTYD30 |
|
| 21 | Rubber Headlight | 61304415000 |
|
| 22 | Bolt Flange 6MM | 90111187000 |
|
| 23 | Bolt Flange 6MM | 90116KVB900 |
|
| 24 | Screw Flange 4X11 | 90125K64N01 |
|
| 25 | Bolt-Washer 6X12 | 90190K64N01 |
|
| 26 | Nut Setting | 90191K64N01 |
|
| 27 | Nut Flange 3MM | 90192K64N01 |
|
| 28 | Nut Setting | 90193K64N01 |
|
| 29 | O-Ring 9.5X1.9 | 91307PLC004 |
|
| 30 | Clip Water Hose 24MM | 91405TK8A01 |
|
| 31 | Clip Tube B10 | 9500202100 |
|
| 32 | Tube 5.3X190 | 950055519020 |
|
| 33 | Bolt Flange 6X22 | 957010602200 |
|
| 34 | Bolt Flange SH 6X16 | 960010601600 |
|
| 35 | Bolt Flange 6X25 | 960010602500 |
|
