| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | Mainshaft Comp (19T) | 23210K64N00 |
|
| 2 | Plate Bearing Setting | 23212K64N00 |
|
| 3 | Countershaft Comp | 23220K64N00 |
|
| 4 | Gear Countershaft First (36T) | 23421K64N00 |
|
| 5 | Gear Countershaft First (36T) | 23431K64N00 |
|
| 5 | Gear M-2 | 23431K64NM0 |
|
| 6 | Gear Countershaft Second (35T) | 23441K64N00 |
|
| 6 | Gear C-2 | 23441K64NM0 |
|
| 7 | Gear Mainshaft Third & Fourth | 23451K64N00 |
|
| 8 | Collar 25X28X10 | 23452KYJ900 |
|
| 9 | Gear Countershaft Third (38T) | 23461K64N00 |
|
| 10 | Collar Spline 25X10 | 23472KYJ900 |
|
| 11 | Gear Countershaft Fourth (27T) | 23481K64N00 |
|
| 12 | Bush 20X23X17.4 | 23482KYJ900 |
|
| 13 | Gear Mainshaft Fifth (27T) | 23491K64N00 |
|
| 14 | Gear Countershaft Fifth (33T) | 23501K64N00 |
|
| 14 | Gear C-5 | 23501K64NM0 |
|
| 15 | Gear Mainshaft Sixth (29T) | 23511K64N00 |
|
| 16 | Collar Spline 23MM | 23512K64N00 |
|
| 17 | Gear Countershaft SIXTH(31T) | 23521K64N00 |
|
| 18 | Sprocket Comp Drive (14T) | 23801K64N00 |
|
| 19 | Pin Gearshift Fork Guide | 24261283000 |
|
| 20 | Bolt Socket 6X14 | 90001K64N00 |
|
| 21 | Bolt Special 10MM | 90037422003 |
|
| 22 | Washer 17X26X1.0 | 90405KYJ900 |
|
| 23 | Washer 20X27X1.0 | 90406KYJ900 |
|
| 24 | Washer Spline 20X26X1.6 | 90451KYJ900 |
|
| 25 | Washer Spline 25X31X1.0 | 90452KYJ900 |
|
| 26 | Washer Spline 25X42X1.6 | 90454KYJ900 |
|
| 27 | Washer Lock 25MM | 90455KYJ900 |
|
| 28 | Washer 10.2MM | 90459438000 |
|
| 29 | Washer Spline 20MM | 90461KRNA80 |
|
| 30 | Washer Lock 20MM | 90462KRNA80 |
|
| 31 | Ring Snap 52MM | 90601K64N00 |
|
| 32 | Circlip EX 20MM | 90601KYJ900 |
|
| 33 | Circlip EX 25MM | 90602KYJ900 |
|
| 34 | Bearing Radial Ball 6304 | 91001GF6004 |
|
| 35 | Bearing Needle 17MM | 91021K64N01 |
|
| 36 | Bearing Needle 17X21X10 | 91026K64N01 |
|
| 37 | Oil Seal 34X52X7.5 | 91205K64N01 |
|
