| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | KIT,FUEL FILTER | 06160KYJ900 | - |
| 2 | CLIP OIL DRAIN TUBE | 15771KV6000 |
|
| 3 | PUMP ASSY.,FUEL | 16700KYJ901 | - |
| 4 | HOLDER,FUEL FILTER | 16912KYJ900 | - |
| 5 | TUBE,FUEL TANK BR | 17418KYJ960 | - |
| 6 | PLATE COMP.,SETTING | 17507KYJ900 | - |
| 7 | TANK SET FUEL(ROSS WHT) | 17520K33D10ZA | - |
| 7 | SET ILL FUEL T(NITRC ORG) | 17520K33D00ZC | - |
| 7 | SET ILL FUEL T(MILL RED) | 17520K33D00ZA | - |
| 8 | STAY TANK LID | 17522K33D00 | - |
| 9 | RUBBER,FUEL TANK | 17525KPPT00 | - |
| 10 | FILM A TANK PROTECTOR | 17527KYJ710 | - |
| 11 | FILM B TANK PROTECTOR | 17528KYJ710 |
|
| 12 | TUBE A FUEL PUMP | 17541KYJ900 | - |
| 13 | TUBE B FUEL PUMP | 17542KYJ900 | - |
| 14 | HOSE COMP FUEL FEED | 17570K33D01 | - |
| 15 | GASKET,FUEL PUMP | 17572KTR941 | - |
| 17 | FASTENER A DUAL L(18X28) | 17580MGZJ00 |
|
| 18 | CUSHION FUEL TANK(B) | 17613K33D00 | - |
| 19 | COLLAR FUEL TANK | 17614K33D00 | - |
| 20 | CUSHION FUEL TANK(A) | 17615K33D00 | - |
| 21 | CAP COMP FUEL FILLER | 17620MCB611 | - |
| 22 | FUEL UNIT | 37800KYJ901 | - |
| 23 | RUBBER SPONGE,TAN | 64455KPPT00 | - |
| 24 | COVER ASSY FUEL TANK | 64700K33D00ZB | - |
| 24 | COVER ASSY FUEL TANK | 64700K33D00ZA | - |
| 25 | COVER ASSY FUEL TANK | 64750K33T70ZA | - |
| 26 | CASE GROMMET | 83551300000 |
|
| 27 | BOLT WASH | 934010601400 |
|
| 28 | NUT,FLANGE 6MM | 9405006000 |
|
| 29 | WASHER, PLAIN, 6MM | 9410306800 |
|
| 30 | TUBE,8X770 | 950058077020 | - |
| 31 | BOLT FLANGE 6X12 | 957010601208 |
|
| 32 | BOLT FLANGE 8X30 | 957010803008 |
|
