| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | DAMPER SET WHEEL | 06410KEA750 |
|
| 2 | SPROCKET FINAL DRIVEN 36T | 41201K33D00 | - |
| 3 | AXLE,RR WHEEL | 42301KYJ900 | - |
| 4 | COLLAR,RR WHEEL SIDE | 42312KYJ900 |
|
| 5 | COLLAR,R RR WHEEL | 42313KYJ900 | - |
| 6 | RING PULSER | 42515KYJ910 | - |
| 7 | FLANGE SUB ASSY RR DRIVEN | 42615K33D00ZA | - |
| 7 | FLANGE SUB ASS R(SAV ORG) | 42615K33D00ZB | - |
| 8 | COLLAR,RR WHEEL DIST | 42620KYJ900 |
|
| 9 | CLLR.B RR DIST | 42625MC4000 | - |
| 10 | 42650K33D00ZA | 42650K33D00ZA | - |
| 10 | 42650K33D00ZB | 42650K33D00ZB | - |
| 11 | WEIGHT, BALANCE(10G) | 42704MERD00 |
|
| 11 | WEIGHT, BALANCE(20G) | 42705MERD00 |
|
| 11 | WEIGHT, BALANCE(30G) | 42706MERD00 |
|
| 12 | TIRE RR TL (140/70-17) | 42711KYJ902 |
|
| 13 | VALVE,RIM (INOUE) | 42753GM9743 |
|
| 13 | VALVE,RIM(TRITON) | 42753KWF901 |
|
| 14 | DISK ,RR BRAKE | 43251KYJ901 |
|
| 15 | DISK ,RR BRAKE | 43251KYJ911 | - |
| 16 | 90105KGH901 | 90105KGH901 | - |
| 17 | BOLT,SPRKT FIX | 90128KYJ900 | - |
| 18 | BOLT,TORX 5X8 | 90131KYJ910 | - |
| 19 | NUT U10MM | 90304KGH901 |
|
| 20 | NUT U FLANGE 16MM | 90306MGZJ01 | - |
| 21 | WASHER,RR SWINGARM | 90559KYJ900 | - |
| 22 | BRG.BL,6204 LBL | 961506204010 | - |
| 23 | BEARING RAD BALL 6203(UU) | 91051KVK901 | - |
| 24 | BEARING, BALL RADIAL,6303 | 961506303010 |
|
| 25 | DUST SEAL,30X47X8 | 91253443761 |
|
| 25 | DUST SEAL,30X47X8 | 91253443762 |
|
| 26 | DUST SEAL,30X47X8 | 91253443761 |
|
| 26 | DUST SEAL,30X47X8 | 91253443762 |
|
| 27 | O-RING 54X2 | 91302317700 | - |
