| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | MAINSHAFT(12T)(WHITE) | 23211K33D00 | - |
| 1 | MAINSHAFT(12T)(BLUE) | 23212K33D00 | - |
| 2 | PLATE,BRG SET | 23212KYJ900 | - |
| 3 | COUNTERSHAFT | 23221KZZ900 | - |
| 4 | GEAR C-1 | 23411K33D00 | - |
| 5 | COLLAR,20X23X10.5 | 23412KYJ900 | - |
| 6 | GEAR M-2 | 23421K33D00 | - |
| 7 | GEAR C-2 | 23431K33D00 | - |
| 8 | COLLAR,22X25X11 | 23432KYJ900 | - |
| 9 | GEAR M-3 M-4 | 23441K33D00 | - |
| 10 | GEAR C-3 | 23451K33D00 | - |
| 11 | COLLAR,25X28X10 | 23452KYJ900 |
|
| 12 | GEAR C-4 | 23471K33D00 | - |
| 13 | COLLAR,SPLINE 25X10 | 23472KYJ900 |
|
| 14 | GEAR MAINSHAFT FIFTH(24T) | 23481K33D00 | - |
| 15 | BUSH,20X23X17.4 | 23482KYJ900 |
|
| 16 | GEAR C-5 | 23491K33D00 | - |
| 17 | GEAR MAINSHAFT SIXTH(26T) | 23501K33D00 | - |
| 18 | COLLAR,SPLINE 23M | 23502KYJ900 | - |
| 19 | GEAR C-6 | 23511K33D00 | - |
| 20 | SPROCKET, DRIVE(14T) | 23801KYJ901 | - |
| 21 | PLATE,FIXING | 23802KYJ900 | - |
| 22 | BOLT DRIVE SOCKET | 90084041000 |
|
| 23 | WASHER,17X26X1.0 | 90405KYJ900 |
|
| 24 | WASHER,20X27X1.0 | 90406KYJ900 |
|
| 25 | WASHER,22X29X1.0 | 90407KYJ900 | - |
| 26 | WASHER,25X32X1.0 | 90408KYJ900 | - |
| 27 | WASHER,SPLINE 20X26X1.6 | 90451KYJ900 |
|
| 28 | WASHER,SPLINE 25X31X1.0 | 90452KYJ900 |
|
| 29 | WASHER,17X28X1.0 | 90453KYJ900 | - |
| 30 | WASHER THRUST 20MM B | 90454KPS900 |
|
| 31 | WASHER,SPLINE 25X42X1.6 | 90454KYJ900 |
|
| 32 | WASHER,LOCK 25MM | 90455KYJ900 |
|
| 33 | CIRCLIP,EX 20MM | 90601KYJ900 |
|
| 34 | CIRCLIP,EX 25MM | 90602KYJ900 |
|
| 35 | BRG,NDL.17X27X13 007 | 91003KYJ901 | - |
| 36 | BRG,BALL RADIAL 6201 | 91005KYJ901 | - |
| 37 | OIL SEAL,22X36X5 | 91207KYJ901 | - |
| 38 | CIRCLIP IN 37MM | 9452037000 | - |
| 39 | BOLT FLANGE 6X14 | 957010601400 |
|
| 40 | BRG.RAD N/COM LBL | 961006304000 | - |
| 41 | BEARING,RADIAL BALL X6203 | 961406203000 | - |
