| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | COIL COMP,IGN | 30510K15921 |
|
| 2 | SPACER IGN COIL | 30520GFM900 |
|
| 3 | CAP ASSY NOISE SUPPRESSOR | 30700KY2702 |
|
| 4 | REG RECT,COMP | 31600K15921 |
|
| 5 | DIODE ASSY,3WAY | 31730MAS601 |
|
| 6 | HARNESS WIRE | 32100K3BN00 |
|
| 7 | SLIDER | 32160K76T61 | - |
| 8 | DUMMY WPC 2P 090M (BLUE) | 32605K59A70 |
|
| 9 | DUMMY,WPC 4P 090 M (RED) | 32606GEV761 |
|
| 10 | RUBTAIL/LT BRKT. | 33714KL3620 |
|
| 11 | SENSOR ASSY,BANK ANGLE M6 | 35160KVS751 |
|
| 12 | HORN COMP (HIGH) | 38110K45N01 |
|
| 13 | COLLAR, HORN SETTING | 38112K41N00 |
|
| 14 | SUSPENSION RELAY CASE(2P) | 38200K56N00 |
|
| 15 | RELAY COMP LED WINKER | 38301K15921 |
|
| 16 | RELAY COMP,MICROISO LOW HIGHT | 38501KVZ631 |
|
| 16 | RELAY COMP., POWER | 38501KWN901 |
|
| 17 | RELAY COMP POWER | 38502K81N01 |
|
| 18 | SUSPENSION, POWER RELAY | 38506MCSG00 |
|
| 19 | UNIT COMP,PGM-FI/IGN | 38770K3BN01 |
|
| 21 | SEAL RING | 38775K76T61 | - |
| 22 | BAND WIRE | 90651KV6003 |
|
| 23 | BOLT HEX 6X20 | 92101060204J |
|
| 24 | BOLT FLANGE 6X10 | 957010601000 |
|
| 25 | BOLT FLANGE 6X16 | 957010601600 |
|
| 26 | BOLT FLANGE 6X18 | 957010601807 |
|
| 27 | BOLT FLANGE 6X14 | 960010601400 |
|
| 28 | FUSE, MINI(5A) | 9820040500 |
|
| 29 | FUSE, MINI(5A) | 9820040500 |
|
| 30 | FUSE, MINI(10A) | 9820041000 |
|
| 31 | FUSE F20A (MINI) | 9820042000 |
|
