| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CRANK SHAFT COMP | 13000K45NA0 |
|
| 1 | CRANK SHAFT COMP | 13000K56N00 |
|
| 2 | RING SET,PISTON STD | 13011K56N01 |
|
| 2 | RING SET,PISTON OS 0.25 | 13021K56N01 |
|
| 2 | RING SET,PISTON OS 0.50 | 13031K56N01 |
|
| 3 | PISTON STD | 13101K56P00 |
|
| 3 | PISTON OS 0.25 | 13102K56P00 |
|
| 3 | PISTON OS 0.50 | 13103K56P00 |
|
| 4 | PIN PISTON | 13111K56N00 |
|
| 5 | CLIP, PISTON PIN, 14MM | 13115KZY700 |
|
| 6 | WEIGHT COMP., BALANCER | 13420K56N00 |
|
| 7 | GEAR A, BALANCER DRIVEN | 13422K45NA0 |
|
| 7 | GEAR B, BALANCER DRIVEN | 13423K45NA0 |
|
| 7 | GEAR C, BALANCER DRIVEN | 13424K45NA0 |
|
| 8 | RUBBER, BALANCER DUMPER | 13425K64NA1 |
|
| 8 | RUBBER,BALANCER DUMPER | 13425KGH901 |
|
| 8 | RUBBER, BALANCER DUMPER | 13425KWC901 |
|
| 9 | SPRING BALANCER GEAR | 13427KPP860 |
|
| 10 | SPRING,THRUST | 13538KGH900 |
|
| 11 | WASHER 28.2X45X1.0 | 90401KPP900 |
|
| 12 | WASHER, 28.1X36X1.8 | 90402KRM840 |
|
| 13 | KEY,WOODRUFF,4MM | 90741KFB000 |
|
| 14 | KEYWOODRUFF 4MM | 90741KGH900 |
|
| 15 | BRG R. RAD BALL,35X72X15 | 91001K56N01 |
|
| 15 | BRG,BALL RADIAL 6207 SPL | 91001KPP901 |
|
| 16 | BRG RAD BALL 12X32X10 | 91003K56N01 |
|
| 16 | BRG,BALL,RADIAL 6201 SPL | 91003KPP931 |
|
| 17 | BEARING, RADIAL BALL, 6301 | 91008K56N01 |
|
| 18 | CIRCLIP EX 28 | 9451028000 |
|
