| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | Rubber Damper RR Set | 41241KW7881 |
|
| 1 | Rubber Damper | 41241KW7882 |
|
| 2 | Adjuster Comp Chain | 40543K07900 |
|
| 3 | Cap Swingarm End | 40546KYY900 |
|
| 4 | Sprocket Comp Final Driven (39T) | 41200K41N00 |
|
| 4 | Sprocket Comp Final Driven (39T) | 41200K41N11 |
|
| 5 | Axle RR Wheel | 42301KPGT00 |
|
| 6 | Sleeve RR Wheel | 42303KBA901 |
|
| 7 | Collar RR Wheel Side | 42304KFM900 |
|
| 8 | Collar R RR Wheel Side | 42313KTM750 |
|
| 9 | Flange Sub Assy Driven | 42615K41N10 |
|
| 10 | Collar RR Axle Distance | 42620KW7881 |
|
| 11 | Cast Wheel RR (MA AX GY) | 42601KVLN11 |
|
| 12 | O-Ring 40.5X3 | 42653001004 |
|
| 13 | Tire RR (80/90-17 NR78Y) | 42711KWB922 |
|
| 13 | Tire RR (80/90-17 FT138) | 42711KWW010 |
|
| 14 | Tube Tire (2.75-17) | 2751700000NR00 |
|
| 15 | Disk RR Brake | 43351KTMN31 |
|
| 15 | Disk RR Brake | 43351KTMN32 |
|
| 16 | Bolt Brake Disk 8X24 | 90105KGH900 |
|
| 17 | Bolt Stud 8X19.5 | 90128KFM900 |
|
| 18 | Nut Special 6MM | 90302KBP900 |
|
| 19 | Nut U 12MM | 90306KGH901 |
|
| 20 | Nut U 8MM | 90309KPH971 |
|
| 21 | Washer RR Axle | 90504KW7901 |
|
| 22 | Oil Seal 26X37X6 | 90753051003 |
|
| 23 | Bearing Radial Ball 6301U L | 91053K03N41 |
|
| 24 | Bearing Radial Ball 6203U L | 91054K03N41 |
|
| 25 | Dust Seal 27X40X4.5 | 91251KGH902 |
|
| 25 | Dust Seal 27X40X4.5 | 91251KPH881 |
|
| 26 | Nut Hex 6MM | 94001060000S |
|
