| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | GASKET SET | 16010KSS901 | - |
| 3 | FLOAT SET | 16013KPG901 |
|
| 5 | CHAMBER SET, FLOAT | 16163GFP901 |
|
| 6 | SCREW SET | 16016KPH901 | - |
| 9 | PLATE SET, VALVE | 16037KPH901 |
|
| 10 | GASKET SET B LBL | 16040GB0911 |
|
| 12 | VALVE SET, AIR CUT | 16048KPH901 |
|
| 13 | O-RING,1.3X4.3 | 16075GHB640 |
|
| 14 | O-RING | 16075GHBB40 |
|
| 15 | CARBURETOR ASSY | 16100K07900 | - |
| 16 | CAP,DUST | 16148141881 |
|
| 18 | VALVE COMP FLOAT | 16155KRS861 |
|
| 19 | GASKET FLOAT CHAMBER | 16163GFP901 |
|
| 21 | CUP,FUEL STAINER | 16175GB0911 |
|
| 22 | CUP,FILTER | 16176GB0911 |
|
| 23 | TUBE, OVERFLOW | 16198GC7004 | - |
| 28 | SCREW WASHER 4X10 | 938920401018 |
|
| 29 | SCREW,WASHER 4X14 | 938920401408 | - |
| 30 | SCREW, WASHER 5X10 | 938920501008 |
|
| 31 | CLIP,TUBE | 9500202659 |
|
| 33 | JET, SLOW 35 | 99103KPH0350 |
|
