| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | COVER OIL FILTER | 15431HF7010 |
|
| 2 | GASKET OIL FILTER | 15439KWB920 |
|
| 3 | WEIGHT SET PRIMARY CLUCTH | 22535KWB305 |
|
| 4 | SPRING,ONEWAY RET LBL | 22606GN5910 | - |
| 5 | PLATE COMP PRIMARY DRIVE | 22610KWB600 | - |
| 6 | INNER COMP ONE WAY CLUTCH | 22630KWB600 |
|
| 7 | SPRING PRIMARY CLUTCH | 22641KWB600 |
|
| 8 | WASHER, CLUTCH SIDE | 22642KFL850 | - |
| 9 | SPG SIDE FRICTION | 22643KFLD00 | - |
| 10 | PLATE, CLUTCH SIDE | 22644KFL851 | - |
| 11 | OUTER ASSY PRIMARY CLUTCH | 22660KWB601 |
|
| 12 | RUBBER CLUTCH DAMPER | 22804GB2000 |
|
| 13 | GEAR COMP PRIMARY DRIVE | 23120KTL740 |
|
| 14 | GEAR SUB | 23122KTL740 |
|
| 15 | RETAINER, SPG | 23123KFL850 | - |
| 16 | SPG,SUB GEAR LBL | 23124GCE900 | - |
| 17 | PIN | 23125GN5910 | - |
| 18 | COLLAR 19X28X4 | 23126KWB600 | - |
| 19 | BOLT,SPL FLANGE 5X8 | 90083KFL850 | - |
| 20 | NUT LOCK 14MM | 90231087010 |
|
| 21 | WASHER,30X45X0,8 | 90401GB2000 |
|
| 22 | WASHER LOCK | 90431GN5910 |
|
| 23 | WASHER BLOCK | 90432086001 | - |
| 24 | WASHER, 17X23X1.5 | 90433KWB601 |
|
| 25 | CIRCLIP,INT 45 MM | 90455GB2000 |
|
| 26 | SET RING 23 MM | 90603P0X000 |
|
| 27 | CIRCLIP 7MM | 90605166720 |
|
| 28 | ROLLER, 5X8 | 91101GB2000 | - |
