| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | COVER,R CENTER SIDE (MT BU SL) | 64350K0WNA0ZC |
|
| 2 | COVER,L CENTER SIDE (MT BU SL) | 64360K0WNA0ZC |
|
| 3 | LID,FUEL | 64405K0WNA0ZB |
|
| 4 | COVER,CENTER (BLK) | 64410K0WNA0ZB |
|
| 5 | COVER,FUEL LID (BLK) | 64415K0WNA0ZB |
|
| 6 | LOCK ASSY FUEL LID | 64440K35V00 |
|
| 7 | HINGE ASSY,FUEL LID | 64450K0WN01 |
|
| 8 | CABLE COMP,FUEL LID | 64455K1ZN21 |
|
| 9 | SPRING, SEAT LOCK | 77234KRJ900 |
|
| 10 | COVER,R BODY (AS BK MT) | 83510K0WNA0ASB |
|
| 10 | COVER,R BODY (AB RD MT) | 83510K0WNA0ARE |
|
| 10 | COVER,R BODY (PL FD WH) | 83510K0WNA0PFW |
|
| 10 | COVER,R BODY (MA PR CR) | 83510K0WNA0MPC |
|
| 10 | COVER,R BODY (MT SO RED) | 83510K0WNA0MSR |
|
| 10 | COVER,R BODY (MT GN BL) | 83510K0WNA0MGB |
|
| 10 | Cover Right Body (MT DI GR) | 83510K0WNA0MDG |
|
| 10 | Cover Right Body (MT FR BR) | 83510K0WNA0MFB |
|
| 11 | COVER,R BODY SIDE | 83600K0WNA0 |
|
| 12 | COVER,L BODY (AS BK MT) | 83610K0WNA0ASB |
|
| 12 | COVER,L BODY (AB RD MT) | 83610K0WNA0ARE |
|
| 12 | COVER,L BODY (PL FD WH) | 83610K0WNA0PFW |
|
| 12 | COVER,L BODY (MA PR CR) | 83610K0WNA0MPC |
|
| 12 | COVER,L BODY (MT SO RED) | 83610K0WNA0MSR |
|
| 12 | COVER,L BODY (MT GN BL) | 83610K0WNA0MGB |
|
| 12 | Cover Left Body (MT DI GR) | 83610K0WNA0MDG |
|
| 12 | Cover Left Body (MT FR BR) | 83610K0WNA0MFB |
|
| 12 | Set Illust L Body Cover Type 5 | 83650K0WNA0ZE |
|
| 13 | COVER,L BODY SIDE | 83700K0WNA0 |
|
| 14 | SET ILLUST,RR CTR CVR TYPE 1 | 83760K0WNA0ZA |
|
| 15 | RIVET,PUSH | 90116K0WNA1 |
|
| 16 | CLIP SNAP FIT(PO) | 90666K59A11 |
|
| 16 | CLIP SNAP FIT | 90666SDAA01 |
|
| 17 | NUT CLIP 5MM. | 90677KANT00 |
|
| 18 | SCREW PAN 5X11.5 | 91509GE2760 |
|
| 19 | SCREW TAPPING 4X12 | 9390324320 |
|
| 20 | SCREW TAPPING 4X12 | 9390324320 |
|
| 21 | SCREW TAPPING 4X12 | 9390324380 |
|
| 22 | SCREW,TAPPING,5X12 | 9390325220 |
|
