| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | BOOT HEADLIGHT | 61312149300 |
|
| 2 | BRKT COMP,FR NUMBER PLATE | 61313K0WNA0 |
|
| 3 | GUARD, NUMBER PLATE | 61316KCJ661 |
|
| 4 | SET ILLUST,WIND SCREEN | 64100K0WNA0ZA |
|
| 5 | Cover Fr Upper | 64336K0WN001AA |
|
| 5 | COVER,FR UPPER (AS BK MT) | 64336K0WN00YA |
|
| 5 | COVER,FR UPPER (AB RD MT) | 64336K0WN00ZB |
|
| 5 | COVER,FR UPPER (PL FD WH) | 64336K0WN00ZK |
|
| 5 | COVER,FR UPPER (MT GN BL) | 64336K0WN00ZD |
|
| 5 | COVER,FR UPPER (MA SO RED) | 64336K0WN00ZW |
|
| 5 | COVER,FR UPPER (MA PR CR) | 64336K0WN00ZX |
|
| 5 | Cover Front Upper (MT FR BR) | 64336K0WN00ZV |
|
| 5 | Cover Front Upper (MT DI GR) | 64336K0WN00ZY |
|
| 6 | COVER,MULTI SW (BLK) | 64337K0WNA0ZB |
|
| 7 | COVER,R FR SIDE (AS BK MT) | 64501K0WNA0ZH |
|
| 7 | COVER,R FR SIDE (AB RD MT) | 64501K0WNA0ZE |
|
| 7 | COVER,R FR SIDE (PL FD WH) | 64501K0WNA0ZF |
|
| 7 | COVER,R FR SIDE (MA PR CR) | 64501K0WNA0ZL |
|
| 7 | COVER,R FR SIDE (MT SO RED) | 64501K0WNA0ZK |
|
| 7 | COVER,R FR SIDE (MT GN BL) | 64501K0WNA0ZB |
|
| 7 | Cover R FR Side (MT FR BR) | 64501K0WNA0ZJ |
|
| 7 | Cover R FR Side (MT DI GR) | 64501K0WNA0ZG |
|
| 8 | COVER,L FR SIDE (AS BK MT) | 64502K0WNA0ZL |
|
| 8 | COVER,L FR SIDE (AB RD MT) | 64502K0WNA0ZF |
|
| 8 | COVER,L FR SIDE (PL FD WH) | 64502K0WNA0ZH |
|
| 8 | COVER,L FR SIDE (MA PR CR) | 64502K0WNA0ZJ |
|
| 8 | COVER,L FR SIDE (MT SO RED) | 64502K0WNA0ZG |
|
| 8 | COVER,L FR SIDE (MT GN BL) | 64502K0WNA0ZB |
|
| 8 | Cover L FR Side (MT DI GR) | 64502K0WNA0ZK |
|
| 8 | Cover L FR Side (MT FR BR) | 64502K0WNA0ZE |
|
| 11 | COVER,FR CENTER | 64503K0WN00 |
|
| 12 | COVER,FR LOWER | 64521K0WNA0 |
|
| 13 | LINK ASSY,SCREEN ADJUST | 64700K0WN01 |
|
| 14 | BOLT SPL 6X16 | 90001MFE670 |
|
| 15 | SCREW PAN 6X15 | 90109K15900 |
|
| 16 | RIVET,PUSH | 90116K0WNA1 |
|
| 17 | SCREW PAN 5X20 (S | 90118MJPG50 |
|
| 18 | NUT, WELL, 5MM | 90156GZ4670 |
|
| 19 | NUT SPRING 4MM | 90302KWWA00 |
|
| 19 | NUT SPRING 4MM | 90302SA4003 |
|
| 20 | NUT,CLIP 6MM | 90305GK8000 |
|
| 21 | WASHER, THRUST 5MM | 90504964000 |
|
| 22 | WASHER, NYLON, 9MM | 90507ZV1000 |
|
| 23 | CLIP SNAP FIT(PO) | 90666K59A11 |
|
| 23 | CLIP SNAP FIT | 90666SDAA01 |
|
| 24 | NUT CLIP 5MM. | 90677KANT00 |
|
| 25 | SCREW PAN 5X11.5 | 91509GE2760 |
|
| 26 | SCREW TAPPING 4X12 | 9390324320 |
|
| 27 | Screw Tapping 4x16 | 9390334421 |
|
| 28 | BRKT,ADJ SCREEN | 64701K0WN00 |
|
| 29 | HOLDER,SCREEN | 64702K0WN00 |
|
| 30 | LINK,ARM | 64703K0WN00 |
|
| 31 | KNOB,ADJ LOCK | 64704K0WN00 |
|
| 32 | SHAFT,A PIVOT | 64705K0WN00 |
|
| 33 | SHAFT,B PIVOT | 64706K0WN00 |
|
| 34 | CLIP | 64707K0WN00 |
|
| 35 | SPG,ADJ PIVOT | 64708K0WN00 |
|
| 36 | STOPPER,ADJ KNOB | 64709K0WN00 |
|
| 37 | SPG,ASSIST | 64710K0WN00 |
|
| 38 | LID,R SCREEN HOLDER | 64711K0WN00 |
|
| 39 | LID,L SCREEN HOLDER | 64712K0WN00 |
|
| 40 | SW ASSY,MULTI | 35300K0WNA1 |
|
| 41 | SCREW TAPPING 4X12 | 9390324380 |
|
