| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CABLE COMP THROTTLE | 17910K16901 |
|
| 2 | SUB CORD, FR. STOP SWITCH | 32103K25900 |
|
| 3 | SWITCH UNIT START | 35160KYZ901 |
|
| 4 | SWITCH UNIT DIMMER | 35170KYZ901 |
|
| 5 | SWITCH UNIT HORN | 35180KYZ901 |
|
| 6 | SWITCH UNIT WINKER | 35200KYZ901 |
|
| 7 | SWITCH ASSY., FR. STOP | 35340KPH901 |
|
| 7 | SWITCH ASSY., FR. STOP | 35340GZ9003 |
|
| 7 | SWITCH ASSY., FR. STOP | 35340K16901 |
|
| 8 | CABLE COMP,FR BRK CONN. | 43440KVB920 |
|
| 9 | CABLE COMP RR BRAKE | 43450K25911 |
|
| 10 | CLAMPER RR BRAKE CABLE | 43455KZL930 |
|
| 11 | WEIGHT A HDL | 53102KVBS00 |
|
| 12 | GRIP COMP THROT | 53140KVBT00 |
|
| 13 | GRIP L HDL | 53166KWB600 |
|
| 13 | GRIP L HDL | 53166K2SN00 |
|
| 14 | HOUSING UP THROT | 53167KFM900 |
|
| 15 | HOUSING UND THROT | 53168KFM900 |
|
| 16 | BRACKET L BRAKE LEVER | 53172K25910 |
|
| 17 | COVER L BRK LEVER BRACKET | 53173GFM900 |
|
| 18 | BAND HDL BRACKET | 53173GFM970 |
|
| 19 | BOOT,BRK LEVER ROD | 53176GBL870 |
|
| 20 | LEVER L STRG HANDLE | 53178K25910 |
|
| 21 | EQUALIZER COMP | 53184K25600 |
|
| 22 | ARM COMP RR BRAKE LOCK | 53185K25910 |
|
| 23 | COVER,RR BRK LOCK LEVER | 53186GBL870 |
|
| 24 | SPG,BRK LOCK ARM RETURN | 53188KVB920 |
|
| 25 | SCREW,HNDL LEVERPIVOT | 90115KWN900 |
|
| 26 | SCREW PAN 5X13 | 90118GFM900 |
|
| 27 | SCREW OVAL 6X45 | 90191KWB600 |
|
| 28 | NUT,U,5MM | 90302KVBT01 |
|
| 29 | BOLT WASHER 6X20 | 934010602000 |
|
| 30 | SCREW PAN 5X12 | 93500050121H |
|
| 31 | SCREW,PAN 5X25 | 93500050250A |
|
